Zeiss CenterMax - Possibilities

7-10
Measuring operation
61211-1020202 CenterMax Operating Instructions
The temperature sensor automatically adapts to the inclination of the
workpiece surface.
A Approaching an oblique workpiece surface
B Probing: Deflection at two points
1 Temperature sensor
2Workpiece
3 Deflection of the probe head
4 Maximum deflection of temperature sensor: ±5°.
Possibilities
A temperature sensing probe offers the following possibilities:
– Temperature compensation.
– Inclusion of the temperature-sensing probe in a CNC program.
– Temperature monitoring.
– Temperature check.
– Temperature recording.
A
2
3
4
B
1
