Probe system
3-5CenterMax Operating Instructions61211-1020202
Probe system
VAST probe head
Environmental conditions
CMM dimensions
Length 91mm
Width 91mm
Height 200mm
Probing directions 6; ±x, ±y, ±z
Measuring force 0.05 to 1N / continuous
Diameter of adapter plate 69mm
Probe head deflection max. ±5mm
Probe weight, max. 600g / incl. adapter plate
Probe length, max. 450mm / stylus + extension
Repeatability following probe
change
<1µm / with 200mm probe
length
Ambient temperature for opera-
tional readiness
+5°C to +40°C
