Preparations for a measuring run
7-15CenterMax Operating Instructions61211-1020202
Signs of the coordi-
nates
Signs of the coordinates: +x, -y and -z.
1 Reference point
2 Measuring volume
3 Safety position
4 Zero point
5 Coordinate system
3
4
1
2
5
