Zeiss CenterMax

To Next Page

To Previous Page

2-18

Description of the CMM

61211-1020202 CenterMax Operating Instructions

Design

A Adapter plate

B RST temperature-sensing probe

C Temperature sensor

1 Connector

2 Knurled ring with internal thread.
