Zetor CRYSTAL Series User Manual

Maximum permissible vertical static load of hitches for trailers and semi-trailers
The maximum weight of an aggregated braked trailer or semi-trailer must not exceed the value
specified on the data plate of the tractor and the value specified in the technical certificate of the
tractor. The maximum permissible speed of the set results from the maximum permissible speed of
the slower vehicle in the set.
Hitch of class C: max. weight of the trailer 6,000kg.
Hitch of class D2: max. weight of the trailer 14,000kg.
Hitch of class D3: max. weight of the trailer 20,000kg.
Hitch type Permissible
vertical
static load
Hitch
pin Ø
Hitch type Permissible
vertical
static load
Hitch
pin Ø
2 000 kg
31 mm
2 000 kg
38 mm
Hitch class D2 Hitch class D3
2 000 kg
43 mm
2 000 kg
50 mm
Hitch class C
2 000 kg
28 mm
TRANSPORTATION
92

Zetor CRYSTAL Series Specifications

General

Transmission	Mechanical or PowerShift
Aspiration	Turbocharged
Hydraulic System	Load Sensing (LS)
Cylinders	6
Hydraulic System Type	Load Sensing (LS)
PTO Speed	540/1000 rpm
Weight Approx	3, 800-5, 500 kg
