ZOLL X Series User Manual

Defibrillator Controls and Indicators
9650-001355-01 Rev.M X Series Operator’s Guide 2-3
Table 2: X Series Controls and Indicators
Control or Indicator Description
Display screen Shows therapeutic settings, physiological waveforms and other
information for each monitored parameter, messages, time, and quick
access key labels.
Quick access keys Seven buttons control different functions of the unit. Labels for the
quick access keys appear on the monitor display to the right of each
key.
Auxiliary power LED Illuminated when the unit is plugged in to an auxiliary power adapter.
Battery charge LED Indicates battery status.
Steady yellow: Battery is charging.
Steady green: Battery is charged.
Alternating green and yellow: The charge state cannot be
determined or a battery charging
fault has been detected.
No light: Battery is not installed.
Visual alarm indicators Red, yellow, and green lights located on the top of the unit that flash
on and off when the unit is powered up and are used to indicate a
patient alert, equipment alert, and data transfer.
PACER button Displays pacer settings window to start/stop pacing activity or change
the rate, output, or mode settings.
ANALYZE button Displays in Manual mode only. Initiates ECG analysis to determine
whether or not a shockable rhythm is present.
ENERGY SELECT
buttons
Two sets of up-down arrow buttons control the selection of
defibrillator energy; one set is located on the front panel and the other
set is located on the STERNUM paddle.
CHARGE Button Charges the defibrillator to the selected energy. In addition to the
CHARGE button on the front panel, there is one located on the APEX
paddle handle.
SHOCK Button
The front panel SHOCK
button is only active when using hands-free
therapy electrodes or internal defibrillation paddles without a
discharge button. The SHOCK button illuminates when the device is
charged and ready.
To discharge the defibrillator when using paddles (internal or
external) with discharge buttons, press and hold the SHOCK buttons
on the paddles.
NIBP button Starts/stops an NIBP measurement.
Snapshot button Records 24 seconds of numeric and waveform data.
PACER

ZOLL X Series Specifications

General

Type	Defibrillator/Monitor
Display	Color LCD
ECG Monitoring	Yes
Pacing	Yes
SpO2 Monitoring	Yes
NIBP Monitoring	Yes
Defibrillator Type	Biphasic
EtCO2 Monitoring	Optional
Data Storage	Yes
Battery	Rechargeable Lithium-ion
CPR Feedback	Real CPR Help
Energy Selection	1-360 J
Pacing Rate	30 – 180 ppm
Pacing Output	0 – 140 mA
Display Size	6.5 inches
Invasive Pressure Monitoring	Optional
Temperature Monitoring	Optional
Wireless Connectivity	Wi-Fi, Bluetooth
