z.one

pro

Service Manual

Page 12 of 217

Symbol

Description

Consult the Instructions for Use

ZONARE serial number

Authorized representative in the European Community

Catalog number

Shipping & Storage: Fragile

Shipping & Storage: Keep dry

Shipping & Storage: Temperature limits

Shipping & Storage: This side UP

Shipping& Storage: Do not stack above this container

Shipping & Storage: Humidity limits

Shipping & Storage: Pressure limits

Federal law restricts this device to sale by or on the order of a licensed

healthcare practitioner (USA).
