System Overview
5 SYSTEM OVERVIEW
Major System Assemblies
Speakers
User Interface
Cable management
Hooks
2 USB ports
17” Display
Storage Bins
Gel Bottle Holder/
Transducer holders
Control Panel
Height Adjust
Left front wheel (black)
And rear wheels – Wheel lock
Power Button
Multi-Transducer
Port (MTP)
Right Front Wheel (Green)
Swivel lock orientation
(Directional lock)
