Using the alpha-numeric keyboard, enter in the required TCP/IP network configuration values/settings in the
appropriate fields, as specified in the information previously provided in the “Pre-Installation Site Survey
Form”, by the medical facility’s IT System Administrator.
Using the Menu Control, arrow down to backlight Apply selection in the main menu, and press one of the
SET keys to save the serial port configuration setup, and exit.
9.1.1 “WIRELESS NETWORK” EQUIPMENT - SETUP
ZONARE supports wireless connectivity using the Quatech (brand) AirborneDirect (model) Wireless
Ethernet Bridge (supported model is the ABDG-ET-DP501, or currently obsolete model ABDG-ET-DP101).
This is a plug-and-play wireless networking solution that is compatible with all ZONARE ultrasound systems
that support Ethernet connectivity. A special power cable, however, is required to supply power to the Quatech
AirborneDirect device from a USB port on the ZONARE system, for portable operations.
The Quatech AirborneDirect Wireless Ethernet Bridge supports WiFi 802.11b/g wireless standards and
connects to the ZONARE system through a 10 Base-T network interface. This device supports WEP (64/128 bit)
and WPA encryption standards, and LEAP for network authentication (LEAP required the Quatech device to be
configured with a static 128 bit key; this is known as "migration mode" and is not recommended for longterm
use due to the static WEP key
requirement). Before using it with the ZONARE system, the Quatech AirborneDirect device must
be preconfigured for the user's networking environment – SSID, channel, encryption, and correct addressing
scheme (DHCP/static).
Static IP addressing is required in order to be able to display the additional wireless status. When power is
applied to a correctly configured Quatech AirborneDirect device that is connected to the Ethernet port on the
ZONARE system, it will require 30 to 60 seconds to detect and then associate with the user's wireless network.
Once a wireless network connection is established, the ZONARE system will reflect the connection state by
showing the network ICON on screen, in an uncrossed state.
The configuration of the Wireless Bridge is done on the Network configuration screen. The source information
required for wireless device configuration on the z.one
pro
, is the static IP Address assigned (by the IT
Administrator at the install site) to the Quatech AirborneDirect device and the Username and Password for
the CLI interface (default is dpac for both).
For assistance with the configuration of the local network settings on the z.one
pro
, to support that aspect of a
wireless network installation, contact Mindray Technical Support.
“FTP” Setup
The “FTP” configuration menu allows for configuring the IP address and Nickname settings for direct network
attached transfer (STORE) operations from the z.one
pro
to remote storage on an FTP server, using the FTP
protocol.
1. Use the Setup button and trackball to advance menu screen to select TOOLS menu, then select
SYSTEM SETUP.
SYSTEM SETUP Menu ARCHIVE Menu
