Transducer TCON Board – Removal/Replacement
Required Parts
 P/N: (as required per transducer type): ........................ TCON Board – Pre-programmed
Different TCON board types (part numbers) exist for the full range of ZONARE transducers.
Below is a table specifying TCON board part numbers applicable for each transducer.
Part Number
86466-00
(Pogo-Pin)
86469-00
(Pogo-Pin)
85010-00
(Old Style)
Probe Types
(where used)
E9-4
L10-5
 L8-3
 L14-5sp
 L20-5
 C6-2
 C9-3
 C9-3sp
 C4-1
 P4-1c
 C10-3
 L14-5W
Required Tools/Equipment
 #3 Tip Phillips-head screwdriver
Overview of Procedure
 Disassemble Connector Housing
 Remove TCON Board and Replace
 Reassemble and Verify Functionality
