IMPORTANT NOTE!
ONLY the following two types of media can be used in the DVD drive on the system.
- DVD: DVD “+R” or “+RW” Type (Not - type)
- CD: CD “-R” Type (Not + type)
Reference http://www.zonare.com/support/accessories/media/ for compatible media
System Verification:
1. Reconnect the main AC power cord from the rear of the system or plug into the wall source.
2. Place AC circuit breaker, located at the rear of the system, in the “1” (ON) position.
3. Press the power button on the system, and allow it to fully boot.
4. Attach a transducer (if not already connected), and ensure basic imaging operation.
5. Insert a blank DVD or CD (type as discussed in Note at top of this section) disk (label facing up)
into the drive. After 3-4 seconds a green disk icon will appear on the top left corner of the cart
display.
6. Go to system archive and export study to the CD. Upon completion, the disk will automatically be
ejected.
7. Verification is complete – return system to normal operation.
