This key only works when in in-progress exam review or archived exam review.
Pressing this key will toggle between the following image formats: 2 x 2,
displaying 2 rows of 2 images (4 images); 3 x 2, displaying 2 rows of 3 images
(6 images); and a full-size image.
This is a toggle key. The first press will display the Patient Selection Table.
The second press will return to imaging.
When an exam is in progress, pressing the End Exam key will close the exam.
If no exam is in progress, pressing this key will have no effect.
This is a toggle key. The first press will display the DICOM queue. The second
press will return to imaging.
CARDIAC Option Systems ONLY: This is a toggle key. The pressing of this
key will activate ECG operation and display the ECG trace on the monitor. A
repeat press will turn off this function.
This is a dual-function key. A “quick” momentary press is a shortcut to bring
up the USER DIAGNOSTIC PANEL screen. An “extended” press will trigger a
capture of a set of current LOG files to the internal archive
This is a toggle key. The first press will display the biopsy needle path guide.
The second press will remove the biopsy needle path guide.
This is a cycling key. Pressing the Body Pattern key will display a Body Pattern
for the Exam Type in use. Pressing the key will cycle through available Body
Patterns, including a blank.
Pressing Del Text will remove all text annotations and arrow graphics
displayed. Pressing Shift+Del Word will delete the most recently entered text
annotation, whether it be free text, POT, or List entry.
Pressing Home will move the text annotation cursor to its default home
position. Pressing Shift+Set Home will set the current cursor position as the
new Home position.
Alternate Graphics. Used in conjunction with the QWERTY keyboard, to
enable access to international characters.
Pressing Text will display the text annotation cursor. Pressing Text again will
remove the text annotation cursor.
This is a toggle key. It works when the image is live or frozen. Pressing the
key displays an arrow graphic in the middle of the display. Up to 15 arow may
be displayed simultaneously.
This is a cycling key. Pressing this key will cycle between displaying LONG,
TRANS, SAG, and COR, for selection as pre-created text annotation.
This is a cycling key. Pressing this key will cycle between displaying RIGHT
and LEFT, for selection as pre-created text annotation.
This is a cycling key. Pressing this key will cycle between displaying PROX,
MID, and DIST, for selection as pre-created text annotation.
Pressing List1 key will display a list of text items entered in List 1.
Pressing List 2 key will display a list of text items entered in List 2.
