Icon
Function
Status Description
Network
Network connected and active
Network
Network disconnected
Network
Network transfer has an error (Re-Queuing of job, etc)
preventing transfer
Wireless
Network
Wireless network connected and active
Wireless
Network
Wireless Network disconnected
Wireless
Network
Wireless Network transfer has an error (Re-Queuing of job,
etc) preventing transfer
Wireless
Network
Wireless signal strength: 1% – 20%
Wireless
Network
Wireless Network Wireless signal strength: 21% – 40%
Wireless
Network
Wireless Network Wireless signal strength: 41% – 60%
Wireless
Network
Wireless Network Wireless signal strength: 61% – 80%
Wireless
Network
Wireless Network Wireless signal strength: 81% –100%
