ZXR102900ESeriesCongurationGuide
ForthedatapacketQoShandlingmethodonthenetworkedgedeviceontheaccessside,
therearethefollowingconditions:
lTheswitchcanselectwhethertotrustthepacketandwhicheldsofthepacket,such
asUPorDSCP,canbetrustedwhenreceivingthepacket.ItallocatestheQoSservice
accordingtotrustedelds.
lWhenthedatapacketreceivedbytheswitchisnottrusted,theQoSserviceis
allocatedaccordingtotherelatedQoScongurationonthereceivingport.
lQoSservicedenestheinternalprocessingmethodandexternalprocessingmethod
ofthepacket.TheinternalprocessingmethodincludesTC,andtheexternal
processingmethodincludesmodifyingthe802.1puserpriorityofadatapacketor
theDSCPdomainofanIPheader.
Forthefollowingnetworkcoredevice,implementtheservicesimilartothepreviousservice
accordingto802.1pofthepacketorDSCPmark.Thisway,asetofend-to-endQoS
serviceisprovided.Whentheowexceedstheconguration,thenetworkdevicecan
modifytheQoSservicelevelsuchasdroppingpacketsorallocatingthelower-levelQoS
service.
Whenadatapacketenterstheport,theswitchwillperformtheQoSinitializationmark
whichmainlyincludestheinitializationofTCQoSparameters.
Inthedirectionofswitchegress,theQoSisusedtoputthepacketintothesuitablequeue
accordingtomarkedTCandperformthecorrespondingqueueschedulingalgorithmand
congestioncontrolalgorithmaccordingtothecurrentqueuecongurationandmodifyit
accordingto802.1puserpriorityorIPDSCPeldofthedatapacket.
ConguringQoS
TheQoScongurationsontheZXR102900Eincludesglobal-basedQoSconguration
andport-basedQoSconguration.PartofQoScongurationisrelatedtoACL.TheQoS
congurationincludesthefollowingcommands:
CommandFunction
zte(cfg)#setqospriority-mappingport<1-28>default-up<0-7>SetsthedefaultportUPpriority.
zte(cfg)#setqospriority-mappingport<1-28>trust-mode
{dscp-priority|port-profile|user-priority}
Setstheporttrustedmode.
zte(cfg)#setqospriority-mappingport<1-28>{remapping-dscp
|remark{dscp-priority|user-priority}}{enable|disable}
SetspacketUP/DSCP
remark/remappingbasedon
theport.
zte(cfg)#setqospriority-mappingqos-profiledscp-to-dscp
<0-63>to<0-63>
Setsthemappingrelationbetween
DSCPs.
zte(cfg)#setqospriority-mappingport<1-28>port-to-profile
qos-profile<0-127>
Setsthemappingrelationbetween
theportandtheQoSprole.
zte(cfg)#setqospriority-mappingqos-profile{up-to-profile
<0-7>|dscp-to-profile<0-63>}qos-profile<0-127>
Setsthemappingrelationbetween
theDSCP/UPandtheQoSprole.
5-54
SJ-20130731155059-002|2013-11-27(R1.0)ZTEProprietaryandCondential
