Zte ZXR10 2900E Series - Figure 5-56 Single-Domain CFM Network with MIP

Chapter5ServiceConguration
Fordeviceconnection,seeFigure5-56.
Figure5-56Single-DomainCFMNetworkWithMIP
lCongurationProcedure
CongurationonS1:
zte(cfg)#cfmenable
zte(cfg)#createcfmmd-session1namezte_1level5
zte(cfg)#createcfmmd-session1ma-session1namezte_zte_1
zte(cfg)#cfmmd-session1ma-session1primary-vlan100
zte(cfg)#createcfmmd-session1ma-session1mep-session1mep-id1
directiondown
zte(cfg)#cfmmd-session1ma-session1mep-id1stateenable
zte(cfg)#cfmmd-session1ma-session1mep-id1ccm-sendenable
zte(cfg)#cfmmd-session1ma-session1mep-id1ccm-receiveenable
zte(cfg)#cfmmd-session1ma-session1mep-id1assignport1
zte(cfg)#createcfmmd-session1ma-session1rmep-session2rmep-id2
remote-mac00.d0.d0.c0.00.03
zte(cfg)#cfmmd-session1ma-session1mep-id2ccm-receiveenable
CongurationonS2:
zte(cfg)#cfmenable
zte(cfg)#createcfmmd-session1namezte_1level5
zte(cfg)#createcfmmd-session1ma-session1namezte_zte_1
zte(cfg)#cfmmd-session1ma-session1primary-vlan100
zte(cfg)#createcfmmd-session1ma-session1mip-session1namezte_mip_1
zte(cfg)#cfmmd-session1ma-session2mip-session1assignport2
zte(cfg)#createcfmmd-session1ma-session1mip-session2namezte_mip_1
zte(cfg)#cfmmd-session1ma-session2mip-session2assignport3
CongurationonS3:
zte(cfg)#cfmenable
zte(cfg)#createcfmmd-session1namezte_1level5
zte(cfg)#createcfmmd-session1ma-session1namezte_zte_1
zte(cfg)#cfmmd-session1ma-session1primary-vlan100
zte(cfg)#createcfmmd-session1ma-session1mep-session1mep-id2
directiondown
zte(cfg)#cfmmd-session1ma-session1mep-id2stateenable
zte(cfg)#cfmmd-session1ma-session1mep-id2ccm-sendenable
zte(cfg)#cfmmd-session1ma-session1mep-id2ccm-receiveenable
zte(cfg)#cfmmd-session1ma-session1mep-id2assignport4
