ZXR102900ESeriesCongurationGuide
CommandFunction
showethernet-oam(allcongurationmodes)DisplaysOAMglobalconguration
information.
showethernet-oamport(allcongurationmodes)DisplaysOAMportsummary
information.
showethernet-oamport<portlist>discovery(allconguration
modes)
DisplaysportOAMdiscovery
state.
showethernet-oamport<portlist>statistics(allconguration
modes)
DisplaysportOAMstatistics
information.
showethernet-oamport<portlist>link-monitor(allconguration
modes)
DisplaysportOAMlinkevent
congurationandstate.
OAMRemoteLoopbackCongurationInstance
lCongurationDescription
OAMremoteloopbackisusedtolocatefailureandexaminethelinkperformance.
ThefunctionisbasedonOAMdiscovery.SeeFigure5-45,theuserlogsintothe
switchAthroughconsoleportandconguresOAM,EnableOAMandtheportremote
loopbackoftheotherend.WhenremoteswitchBisontheOAMremoteloopback
mode,thestatisticdataoflocalandremoteswitchcanbeinquiredandcomparedat
anytime.OAMloopbackframecanbeanalyzedtoobtaintheadditionalinformation
oflinkhealth(framediscardduetothelinkfailure).
Figure5-45RemoteLoopNetwork
lCongurationProcedure
1.CongurationofswitchA:
zte(cfg)#setethernet-oamen
zte(cfg)#setethernet-oamport1en
2.CongurationofswitchB:
zte(cfg)#setethernet-oamenable
zte(cfg)#setethernet-oamport2enable
zte(cfg)#showEthernet-oamport2discovery
PortId2:ethernetoamenabled
LocalDTE/*thelocaldeviceinformation*/
-----------
Config:
Mode:active
/*theportmodemustbeactive,orthediscoveryisfailure*/
5-128
SJ-20130731155059-002|2013-11-27(R1.0)ZTEProprietaryandCondential
