ZXR102900ESeriesCongurationGuide
1128.1200000ForwardRootSSTPNone
2128.2200000DiscardAlternateSSTPNone
RSTPCongurationInstance
lCongurationDescription
ConguretheRSTPfunctionofswitch1andswitch2,takeswitch1astherootbridge
andblockaredundantportintheloop.Thisrealizesloopprotectionandlinkbackup
betweenswitches.SeeFigure5-10.
Figure5-10RSTPCongurationInstance
lCongurationProcedure
zte(cfg)#setstpenable
/*enableSTPprotocolofswitch1andswitch2*/
zte(cfg)#setstpforceversionrstp
/*setforceversionofstpasrstp*/
lCongurationVerication
1.ChecktheSTPstateofswitch1inthesystemview.
zte(cfg)#showstpinstance
Spanningtreeenabledprotocolrstp
RootID:
Priority:32768Address:00.d0.d0.02.00.54
HelloTime(s):2MaxAge(s):20
ForwardDelay(s):15
RegRootID:
Priority:32768Address:00.d0.d0.02.00.54
RemainHops:20
BridgeID:
Priority:32768Address:00.d0.d0.02.00.54
HelloTime(s):2MaxAge(s):20
ForwardDelay(s):15MaxHops:20
InterfacePortIdCostStatusRoleBoundGuardStatus
--------------------------------------------------------
1128.1200000ForwardDesignatedRSTPNone
2128.2200000ForwardDesignatedRSTPNone
2.ChecktheSTPstateofswitch2inthesystemview.
zte(cfg)#showstpinstance
Spanningtreeenabledprotocolrstp
RootID:
Priority:32768Address:00.d0.d0.02.00.54
HelloTime(s):2MaxAge(s):20
5-40
