ConguringaTimeRange
Thetimerangecongurationincludesthefollowingcommands:
CommandFunction
zte(cfg)#settime-range<word>period<hh:mm>to
<hh:mm>{daily|day-off|day-working|monday|tuesday|
wednesday|thursday|friday|saturday|sunday}
Setsaperiodictimerange.
zte(cfg)#settime-range<word>absolute<hh:mm><yyyy-mm-d
d>[to<hh:mm><yyyy-mm-dd>]
Setsanabsolutetimerange.
zte(cfg)#cleartime-range[<word>]Clearstimerangeconguration.
showtime-range[<word>](allcongurationmodes)Displaystimerangeconguration.
5.41VoiceVLANConguration
VoiceVLANOverview
TheVoiceVLANisaVLANspeciallyallocatedforvoicedataofusers.Itprovidesavoice
VLANandaddsinterfacesofvoicedevicestothevoiceVLAN.Theusercancongure
theCoSandDSCPforvoicedatatoincreasethepriorityofvoicedatatransmissionand
ensurethecallquality.
VoicedatacanbeaddedtothevoiceVLANintwomodes:dynamicmodeandmanual
mode.
Indynamicmode,iftheinterfacefailstobeaddedtoorremovedfromthevoiceVLAN,the
systemwillsendanalarmtonotifytheuser.
TopreventcommonservicepacketsfromoccupyingthebandwidthofthevoiceVLANand
ensurethequalityofvoicecommunication,thevoiceVLANprovidesthesecuritymode.
Thesecuritymodeisclassiedintothestrictsecuritymodeandnon-strictsecuritymode.
ConguringaVoiceVLAN
ThevoiceVLANcongurationincludesthefollowingcommands:
CommandFunction
zte(cfg)#setvlanvoice-vlanport<port-id>ingress-vlan
<vlanlist>voice-vlan<1-4094>
SetsthevoiceVLANfunctionon
aport.
zte(cfg)#setvlanvoice-vlanport<port-id>oui-id
<1-32>mac-addr<HH.HH.HH.HH.HH.HH>mac-mask
<HH.HH.HH.HH.HH.HH>
AddsanOUItoaport.
zte(cfg)#setvlanvoice-vlan<1-4094>qos-profile<0-127>
modify{up|dscp|all}
Setstomodifyeitherupordscp
orboth.
