Chapter5ServiceConguration
CommandFunction
showlldpstatisticport<portlist>(allcongurationmodes)Displaysstatisticsinformationof
LLDPneighbors.
LLDPCongurationInstance
lCongurationDescription
SeeFigure5-48,twoswitchesareconnectedtoeachotherthroughatwisted-pair.By
default,theLLDPfunctionisenabled,andallparametersusethedefaultvalues.Use
theshowcommandtoviewneighborestablishmentinformation.
Figure5-48LLDPCongurationInstance
lCongurationVerication
zte(cfg)#showlldpneighbor
CapabilityCodes:
P-Repeater,B-Bridge,W-WLANAccessPoint,R-Router,T-Telephone
C-DOCSISCableDevice,s-Station,S-Switch,O-Other
InterfaceDeviceIDHdtmCapabilityPlatformPortID
--------------------------------------------------------------------------
port-1900.d0.d0.09.29.18110BSZXR102918E-PSport-9
VersionV2.05.11B06
zte(cfg)#showlldpentry
--------------------------------------------------------
LocalPort:port-1/1
ChassisID:00.55.43.33.33.59(MACAddress)
PortID:port-1/48(InterfaceName)
TTLID:102(Timetolive)
PortDescription:port-1/48statusisup,media-typeis1000BaseT,pvidis4094.
SystemName:52PM
SystemDescription:ZXR102918E-PSVersionV2.05.11B06
SystemCapability:Bridge,Switch
ManagementAddress:IPv4-192.168.100.100,ifIndex-63,OID-Null
5.37SinglePortLoopDetectionConguration
SinglePortLoopDetectionOverview
Singleportloopdetectionistocheckwhetheraloopexistsintheportsoftheswitch.Ifsuch
aloopexists,itmayresultinerrorsinlearningMACaddressesandmayeasilycausea
broadcaststorm.Inseverecase,switchandnetworkmaybedown.Startingthesingleport
