ZXR102900ESeriesCongurationGuide
Figure6-22PortStateInformationPage
Thispagedisplaysthefollowingportinformation:
ParameterDescription
PortClassPortclass
LinkStatePortlinkup/linkdownstate
DuplexDuplexworkingstateoftheport
SpeedWorkingspeedoftheport
Note:
Portlinkdownmeansthatporthasn’taphysicalconnection.Thedisplayedvaluesof
“Duplex”and“Speed”aremeaningless.
PortCongurationInformationCheck
Clickthedirectorytreeontheleftofthemainpage,Conguration>Port>Port
Parameter.Theportcongurationinformationpageisdisplayed,seeFigure6-23.
6-32
SJ-20130731155059-002|2013-11-27(R1.0)ZTEProprietaryandCondential
