ZXR102900ESeriesCongurationGuide
Figure6-35BulkAggregationPortCongurationPage
Aftersettingattributesoftheaggregationportonthispage,clickApplytosubmit.
AggregationGroupInformationCheck
ClickConguration>Lacp>LacpStateontheleftofthemainpage.The
aggregationgroupinformationpageisdisplayed,seeFigure6-36.
Figure6-36AggregationGroupInformationPage
Thispagedisplaysthefollowinginformation:
ParameterDescription
AttachedPortsAttachedportsintheaggregationgroup
ActivePortsActiveportsintheaggregationgroup
GroupModeAggregationmodeoftheaggregationgroup
6-42
SJ-20130731155059-002|2013-11-27(R1.0)ZTEProprietaryandCondential
