PortNumGroupNumGroupModeLacpTimeLacpActive
-------------------------------------------------------
153DynamicLongTrue
163DynamicLongTrue
zte(cfg)#showlacpaggregator3
Group3
ActorPartner
--------------------------------------------------------
Priority:3276832768
Mac:00.d0.d0.fa.29.2000.d0.d0.fc.88.63
Key:258258
Ports:16,1516,15
Theabovedisplayedresultprovesthatthelinkaggregationissuccessful.Ifitisnot
successful,theresultisshownasfollowsafterexecutingtheshowlacpaggregator3
command.
zte(cfg)#showlacpaggregator3
%Group3isnotactive!
Theaboveresultisduetophysicallinkfailure.Itisrecommendedtocheckthephysical
linkstatus.
5.7IGMPSnoopingConguration
IGMPSnoopingOverview
Becausethemulticastaddressisnotinthesourceaddressofthepacket,theswitchcannot
learnthemulticastaddress.Whentheswitchreceivesamulticastmessage,itsendsthe
messagetoalltheportsinthesameVLAN.Ifnomeasureistaken,unwantedmulticast
messagesmaybespreadtoeachnodeofthenetwork,causingagreatwasteofnetwork
bandwidthresource.
WiththeIGMPSnoopingfunction,theIGMPcommunicationbetweenthehostandrouter
issnooped,sothatthemulticastpacketsaresenttotheportsinthemulticastforwarding
table,insteadofallports.ThisrestrictstheoodingofmulticastmessagesintheLAN
switch,reducesthewasteofnetworkbandwidth,andimprovestheutilizationrateofthe
switch.
ConguringIGMPSnooping
TheIGMPSnoopingcongurationincludesthefollowingcommands:
CommandFunction
zte(cfg)#setigmpsnooping{enable|disable}EnablesordisablestheIGMP
Snoopingfunction.
