Chapter5ServiceConguration
CommandFunction
showloopdetect(allcongurationmodes)Displaysloopdetection
information.
showloopdetectport[<portlist>](allcongurationmodes)Displaysportinformationofloop
detection.
showloopdetecttrunk[<trunklist>](allcongurationmodes)Displaystrunkinformationofloop
detection.
zte(cfg)#clearloopdetectClearsloopdetectionconguration
information.
SinglePortLoopDetectionCongurationInstance
lCongurationDescription
SeeFigure5-49,congurethesingleportloopdetectionfunctionsothatPort1on
Switch1candetectthelooponSwitch2andblockPort1.
Figure5-49SinglePortLoopDetectionCongurationTopology
lCongurationProcedure
zte(cfg)#setloopdetectport1enable
lCongurationVerication
ChecktheloopdetectionstateofSwitch2:
zte(cfg)#showloopdetect
Theblock-delayofloopdetect:5(min)
Thepacketintervalofloopdetect:15(sec)
PortIdisUpisStpisProtectisExtendloopVlanNumloopType
----------------------------------------------------
1UpNoYesNo1Port
zte(cfg)#showloopdetectport1
PortId:1
VlanIdisLoopisBlock
-------------------
1YesYes
