Zte ZXR10 2900E Series - Figure 5-53 Voice VLAN Configuration Instance

Chapter5ServiceConguration
CommandFunction
zte(cfg)#setvlanvoice-vlan<1-4094>qos-profiledisableDisablestheassociationbetween
aQoSproleandavoiceVLAN.
zte(cfg)#clearvlanvoice-vlanport<port-id>ClearsallvoiceVLANinformation
conguredonaport.
zte(cfg)#clearvlanvoice-vlanport<port-id>oui-idClearsallOUIsconguredona
port.
zte(cfg)#clearvlanvoice-vlanport<port-id>oui-id<1-32>ClearsaspecicOUIcongured
onaport.
showvlanvoice-vlan(allcongurationmodes)Displaysvoicecongurationonall
ports.
showvlanvoice-vlanport<port-id>(allcongurationmodes)Displaysvoicecongurationona
port.
showvlanvoice-vlandefault-oui(allcongurationmodes)DisplaysthedefaultOUIofa
device.
showvlanvoice-vlanuser-tableport<port-id>(allconguration
modes)
Displaystheusertableonaport.
showvlanvoice-vlan<vlanlist>qos(allcongurationmodes)DisplaysvoiceVLANQoS
conguration.
VoiceVLANCongurationInstance
lCongurationDescription
SeeFigure5-53,thetwoIPPhonesareinVLAN10andVLAN20,respectively.The
voiceVLANisVLAN100.
Figure5-53VoiceVLANCongurationInstance
lCongurationProcedure
zte(cfg)#setvlan10,20,100addport1-3tag
zte(cfg)#setvlan10,20,100enable
zte(cfg)#setvlanvoice-vlanport1oui-id1mac-addr00.00.01.00.00.01
