Chapter5ServiceConguration
CommandFunction
showmaclearningexceptsession[<1-100>]Displaysthecongurationofsessionsfor
whichspeciedsourceMAClearningis
notneeded.
showmaclearningexcept{port<portlist>|trunk<trunklis
t>}
Displaysthebindingrelationbetween
ports/trunksandsessions.
showmacprotect[portlist]DisplaystheMACprotectionstatetocheck
whetherMACprotectionistriggered.
5.6LACPConguration
LACPOverview
TheLinkAggregationControlProtocol(LACP)isastandardprotocoldenedinIEEE
802.3ad.
Linkaggregationmeansthatphysicallinkswiththesametransmissionmediaand
transmissionrateare“bound”together,makingthemlooklikeonelinklogically.This
conceptisalsoknownasTrunk.Itallowssimultaneousmultipliedincreaseofthe
bandwidthsofparallelphysicallinksbetweentheswitchesorbetweentheswitchandthe
server.Asaresult,itbecomesanimportanttechnologyinincreasingthelinkbandwidth
andcreatinglinktransmissionexibilityandredundancy.
Anaggregatedlinkisalsocalledtrunk.Ifaportofthetrunkisblockedorfaulty,thedata
packetswillbedistributedtootherportsofthistrunkfortransmission.Ifthisportrecovers,
thedatapacketswillberedistributedtoallthenormalportsofthistrunkfortransmission.
TheZXR102900Esupportsupto15aggregationgroups.Ineachaggregationgroup,the
numberofaggregatedlinksdoesnotexceedeight.
ConguringLACP
TheLACPcongurationincludesthefollowingcommands:
CommandFunction
zte(cfg)#settrunk<trunklist>pvid<1-4094>SetsthedefaulttrunkVID.
zte(cfg)#setlacp{enable|disable}EnablesordisablestheLACP
function.
zte(cfg)#setlacpaggregator<1-15>{add|delete}port<portlist>Addsordeletesaspeciedport
to/fromanLACPaggregation
group.
zte(cfg)#setlacpaggregator<1-15>mode{dynamic|static|
mixed}
Setsaggregationmodeofan
LACPaggregationgroup.
