CommandFunction
showmldfilterquery(allcongurationmodes)Displaysthecongurationofthequerypacket
lter.
showmldfilterqueryvlan<vlanlist>(all
congurationmodes)
Displaysthecongurationofthequerypacket
lterforthespeciedVLAN.
MLDSnoopingCongurationInstance
lCongurationDescription
SeeFigure5-5.Port1,Port3andPort5areconnectedtohosts,Port10isconnected
toarouter,ports10,1,3and5areinVLAN200,usersconnectedtoPorts1,3and5
sendmulticastjoinrequeststojointhegroupsff1e::22andff1e::11.EnabletheMLD
snoopingfunctionontheswitchanddisplaythesnoopingresult.
Figure5-5MLDSnoopingCongurationInstance
lCongurationProcedure
zte(cfg)#setvlan200addport1,3,5,10untag
zte(cfg)#setport1,3,5,10pvid200
zte(cfg)#setvlan200enable
zte(cfg)#setmldsnoopingenable
zte(cfg)#setmldsnoopingaddvlan200
zte(cfg)#setmldsnoopingvlan200addmrport10
lCongurationVerication
Displaythesnoopingresult:
zte(cfg)#showmldsnoopingvlan200
MLDSnooping:enable
Querier:disable
WorkingMode:proxy
