lLinkMonitoring:TheZXR102900Eseriesswitchmonitorsandexaminesthelink
state,andannouncesthespeciedframeeventsbyOAMfunction.Thespecied
frameeventscanbeclassiedintofourtypes:errorsymbolperiodevent,error
frameeventanderrorframeperiodevent,errorframe-secondstatisticevent.After
inspectingtheerror,OAMwillrespondandalarmthepeerdevicebyannouncement
mechanism.
Thelinkmonitoringeventsareclassiedintofourtypes:errorsymbolmonitorevent,error
framemonitorevent,errorframe-periodmonitoreventanderrorframe-secondstatistic
monitorevent.Whenthelinkmonitoringinformationisviewed,therelatederrorsymbol,
thestatisticoferrorframeandthestatisticoflocalandpeerlinkeventswillbeshownon
eachevent.
ConguringOAM
TheOAMcongurationincludesthefollowingcommands:
CommandFunction
zte(cfg)#setethernet-oam{enable|disable}Enablesordisablestheglobal
OAMfunction.
zte(cfg)#setethernet-oamport<portlist>{enable|disable}EnablesordisablestheOAM
functionontheport.
zte(cfg)#setethernet-oamport<portlist>period<1-10>
timeout<2-20>mode{active|passive}
SetstheOAMperiod,timeouttime
andmodeoftheport.
zte(cfg)#setethernet-oamremote-loopbacktimeout<1-10>Setsremote-loopbacktimeout
valueonport.
zte(cfg)#setethernet-oamremote-loopbackport<portlist>{start
|stop}
StartsorstopsOAM
remote-loopbackfunctionon
port.
zte(cfg)#setethernet-oamorg-specific{oui<XX-XX-XX>|
time-stamp<1-10>}
Setsthespeciedcontentin
OAMPDUpacket.
zte(cfg)#setethernet-oamport<portlist>link-monitor{enable|
disable}
Enablesordisableslinkmonitor
function.
zte(cfg)#setethernet-oamport<portlist>link-monitor
symbol-periodthreshold<1-65535>window<1-65535>
Setsthesymbolperiodevent
whichisusedforlinkmonitor.
zte(cfg)#setethernet-oamport<portlist>link-monitorframe
threshold<1-65535>window<1-60>
Setstheerrorframe.
zte(cfg)#setethernet-oamport<portlist>link-monitor
frame-periodthreshold<1-65535>window<1-600000>
Setstheperiodoferrorframe.
zte(cfg)#setethernet-oamport<portlist>link-monitor
frame-secondsthreshold<1-900>window<10-900>
Setserrorframesummary.
