ZXR102900ESeriesCongurationGuide
StepCommandFunction
1ZXR10(config)#setERPSdomain<1-4>
protect-instance<1-16>
CreatesanERPSdomain.
2ZXR10(config)#seterpsdomain
<1-4>ring-id<1-239>raps-vlan
<1-4094>{ring-east{port<portid>|trunk
<portid>}ring-west{port<portid>|trunk
<portid>}}[rpl-role{owner|neighbour}
rpl-port{east|west}]
ConguresanERPSringnode.
Theraps-vlanparametershouldspecifya
service-unrelatedVLAN(notconictedwith
anyoftheVLANsforservicesandnetwork
management).TheportPVIDmustnotbe
thesameasthesettingoftheraps-vlan
parameter.
Thesettingofthering-idparameteris
carriedintheprotocolmessage,varying
withtheERPSinstance.
3ZXR10(config)#seterpsdomain<1-4>
ring-mel<1-7>
Conguresthemelfortheringnode.
4ZXR10(config)#seterpsdomain<1-4>
behaviour{revertive|non-revertive}
Speciesthereveriveornon-revertive
modeforthering.
5ZXR10(config)#seterpsdomain<1-4>
timerwtr-time<1-12>
CongurestheWTRtime(inminutes)of
theERPSring.
TheWTRtimer(inminutes)isvalidforthe
RPLownernodeonly,range:1–12,default:
5.
6ZXR10(config)#seterpsdomain<1-4>
timerguard-time<1-200>
Congurestheguardtimertime(inunitsof
10ms)fortheERPSring,
Range:1–200,default:50.
7ZXR10(config)#seterpsdomain<1-4>
switch{{fs|mseast|west}|clear}
Conguresthemanualswitchingcommand
fortheERPSring.
AftertheFS/MScommandisexecuted,the
correspondingportissettoblockstatus.
8showERPSbriefDisplaystheprimarycongurationofeach
ERPSdomain.
9showERPSdomain<1-4>Displaysdetailedinformationaboutthe
ERPSdomain.
CongurationExampleofaSingleERPSDomain
Figure5-70showsthatanERPSdomainisconguredonswitchesAtoD.Thistypeof
congurationiscalledsingle-domain,single-ring.Thecongurationisasfollows:
lProtectioninstance1isconguredfortheERPSdomain.Inthisinstance,the
dedicatedVLAN(VLAN4000)isusedtoprotectVLANs100to110.
lSwitchAistheownernode,anditsport1/2isanRPLport.
lSwitchBistheneighbornode,anditsport1/2isanRPLport.
5-174
