Go!Control Wireless Security System | Install Guide
WIRELESS INSTALLATION TIPS
Wheninstallinganywirelesssystem,consider
certainlimitations.Lowpowerwirelesstransmitter
signalsdoNOTbroadcastequallythroughalltypes
ofconstructionmaterials.However,theControl
Panelcontainsaverysensitivereceiverthatshould
allowforplacementoftransmittersinalmostall
locations.Reviewthefollowingillustrationbefore
beginningtheinstallationfo
rthebestpossi
ble
placementofwirelesssensors.
CONTROL PANEL MOUNTING
PLATE
MounttheControlPanelonthewallinaneasy
location(oroptionaldeskmount)forthe
subscribertooperatethesystem.
Somespecialtoolsmayberequiredtomountthe
ControlPanelontothewall:
• Screwdriver
•Wires
tripper
•St
aplegun
•Drywallsa
w(orequi
valent)
• Ladder
1 Removethelockingscrewfromthetopofthe
ControlPanelcaseandremovethemounting
plate.
2 Usethemountingplateasatemplatetomark
thewallforthewiring cutoutslot.Usea
drywallsawtocuttheslot.Ifusingthe
optionalCellRadioModulewithanexternal
antenna,removetheplasticknockoutlabeled
“EXTERNALANTENNA”onthemountingplate.
Markandcutaslotinthedr
ywallforthe
ex
ternalantenna.
3 Attachthemountingplatetothewallusing3
screws.
A Mountingplate
B Removecasescrewandmountingplate
C Usemountingplateasatemplatetomarkwirecutout
holeindrywall.
D Ifusingexternalantenna,removeknockoutplate.
E Mountplatewith3screws.
WIRELESS SENSORS
Followingtheinstructionsincludedwitheach
wirelesssensor,installeachsensoratitsdesired
location.
