CONTROL PANEL INTERNAL FEATURES
A BackupBatteryPack 7.2VoltNi‐mhbatterypackisincludedwiththeControlPanel,replacementpartnumber
2GIG‐BATT1.
B TelephoneJack UsedforRJ45connectiontoinstallation'sRJ31Xtelephonejack.
C TerminalBlock Connectionsforpower,solidstateoutputbell,andhardwireloops.
D AlternatePowerSupply Alternateconnectionforpower.(Plug‐inbarrelconnector)
E J4PinConnector ConnectorfortheFirmwareUpdateCableusedtoupdatethefirmwareversiononthe
ControlPanel.
F OptionalReceiverModule Moduleforover‐the‐aircommunicationwiththeCentralStation.
G MainReceiverModule 345MHzreceiverforwirelesssensorsOptionalModelXCVR2345/900MHztransceiver
fortouchscreenkeypads.
H POTSModule(OPTIONAL) POTS(PlainOldTelephoneSystem)Moduleforconnectinglineman's"buttset"for
monitoringthetelephoneline.
I THIRDHANDHangerStrap HooksontomountingplateduringinstallationtoholdtheControlPanelwhilewiring.
