©2013 2GIG Technologies Inc. All Rights Reserved. 35
WIRED SENSOR PROGRAMMING STEPS
Q-2 SELECT WIRED SENSOR #
(1-2)
Twohardwiredloopscanbeusedassensorswith
eachControlPanel.Theoptionsforeachwired
sensorareprogrammedwithsub‐optionquestions.
•Beginbyen
te
ringthewiredsensornumberor
selectitusingthe←or→arrows.
•Afterselectingthewire
dsensornu mber,
programthewiredsensordetailsbyusingthe
↑and↓arrowstoselecteachofthesub‐
options.
NOTE: Toskipwiredsensorprogramming,
pressSkiptojumpfromquestionQ‐2to
questionQ‐3(RFkeyfobprogramming).
Select wired sensor (#) type
DEFAULT: Unused (00)
Eachwiredsensorneedstobeassignedtoasensor
type.
Selectthesensortypethatmatchesthewired
sensor’sfunconusingthe←or→arrowsorenter
thesensortypenumberdirectlyonthekeypad.
Select wired sensor (#) equipment
type
DEFAULT: Varies by wired sensor type
Thisquestionisonlydisplayedwhencertainsensor
typesareselected.
Theequipmenttypeselectionwillaffectthe
sensor’sextendedreportingcode.
Thefollowingsensortypesrequireequipmenttype
selection:
• Selecttheequipmen
ttypethatmat
chesthe
sensorequipmentusingthe←or→arrows,or
entertheequipmenttypenumberdirectlyon
thekeypad.
NOTE: ThisControlPaneldoesnotprovide
auxiliaryaccessoryoutputpower.
Connectingahard
wirePIRusingequipmenttype
“motion”willrequireanexternalstand‐alone
batterybacked‐uppowersupplyforthePIR.
Select wired sensor (#) equipment
code (0-9999)
DEFAULT: (0)
Thewiredsensorequipmentcodedefinesthe
sensor’smanufacturerandtype.
•Enterthe4‐digitequipmentcodefo
rthe
sensor.
Select wired sensor (#) equipment
age (0-1)
DEFAULT: New (0)
TheControlPanelcanbeusedwithneworexisting
wiredsensors.
•Ifthiswiredse
nsorisnewfortheinstallation,
leavethedefaultofnew(0).
•Ifthiswiredse
nsorisalreadyinstalled,select
existing(1).
Sensor Types
(00)unused
(01)exit/entry1
(02)exit/entry2
(03)perimeter
(04)interiorfollower
(05)dayzone
(06)24‐hoursilentalarm
(07)24‐houraudiblealarm
(08)24‐hourauxiliaryalarm
(09)24‐hourfire
(10)interiorwithdelay
(14)24‐hourcarbonmonoxide
(16)24‐hourfireverification
(23)noresponsetype
(24)silentburglary
SensorType EquipmentTypesAvailable
(04)interiorfollower (1)=motion(2)=contact
(06)24‐hoursilent
alarm
(1)=contact(11)=emergency
(07)24‐houraudible
alarm
(1)=contact(11)=emergency
(08)24‐hourauxi liar y (1)=contact(6)=freez e(8)=water
(10)=termperature(11)=emergency
(10)interiorwithdelay (1)=motion(2)=contact
(23)noresponsetype (1)=contact(2)=motion
