Go!Control Wireless Security System | Install Guide
BACKUP BATTERY
CONNECTION AND POWER
SUPPLY WIRING
ThebackupbatteryconnectstotheControlPanel’s
circuitboardwitha2‐pinheaderassembly.
Thepowersupplyfeaturesa2‐positionterminal
blockforconnectingthepowersupplytothe
ControlPanelpowerterminals(connectionwire
notincluded).
1 Determineagoodlocationwherethere’sa
walloutletfortheplug‐inpowersupply.The
walloutletmustbeun‐switched.
NOTE: Donotconnectthepowersupplytoa
receptaclecontrolledbyaswitch.
2 Route2‐conductorwirefromthepower
supplylocationtotheControlPanelmounting
plate.Forwiresizeandmaximumlength,see
WireSi
zeandLe
ngthbelow.
3 Beingcarefultoobservepolarity,connectthe
wiretothepowersupply’sDC+andDC‐
terminals.Donotpluginpowersupplyyet.
4 Beingcarefultoobservepolarity,connectthe
wiretotheControlPanelinputterminals
14VDC(+)Terminal #1and14VDC(‐)Termina l
#2.
NOTE: GroundingoftheControlPanelisNOT
requiredforproperoperation.
5 Plugthebackupbatterypack’ sconnectorinto
theconnectorontheControlPanel’ scircuit
board.(TheControlPaneldoesnotrecognize
thatthebatteryisconnecteduntilACpoweris
connectedtothepowersupply).
NOTE: Applicableregulatoryagenciesrequire
installationoftheextendedlifebackup
batteryinsidetheControlPanelfor24‐
hourbatterybackupapplications.
Wire Size and Length
Toensureproperoperation,DoNotexceedthe
followingmaximumlengthforthewiresize
installed:
Toensurethattheappropriatewiresizeandlength
areinstalled,measurethevoltagebetweenthe
powerconnectionterminalsatthebackofthe
controlpanel.Thevoltagemeasuredmustnotfall
below11voltsDCornuisance“A
CPow
erLoss”
messagesmaybedisplayedandreported.
NOTE: IntheUnitedStates,wiringrouted
insidewalls,ceilings,andfloorsmust
complywithrequirementsoftheNational
ElectricalCode,ANSI/NFPA70andlocal
buildingcodes.Forwiringfromtheoutput
ofthe2GIGclassIIpowersupply,wiring
ratedCL2,CL2X,CL2R,orPLTCis
recommendedtosatisfythese
requirements.Ifthiswiringisins
tall
edin
anairplenum(spaceusedfor
environmentalairexchange)itmustbe
ratedCL2P(plenumrated).
A LeftTermina l14VDC(+) C 14VDC(+)Termi nal#1
B RightTermin al14VDC(‐) D 14
VDC(‐)Term ina l#2
Control Panel and Power Supply
Wiring
Withallthewiringcomplete,theControlPanelis
readytopowerup.
1 Swingthe ControlPanelup,placingthe
bottomoverthelipofthemountingbracket.
PushthetopoftheControlPanelintothe
mountingbracketuntilitsnapsintoplace,
thensecureitwiththeretainingscrew.
Wire Size Maximum Length
22AWG 55feet(16.8meters)
20AWG 85feet(25.9meters
22AWG2‐pairs
(19AWGequivalent)
110feet(33.5meters)
18AWG 135feet(41.1meters)
