SYSTEM STATUS ICONS
ThetoplineoftheControlPanel’ sdisplayisthe
statusbarthatshowsthecurrentsystemmode,the
statusofthesensors,andanycurrentsystem
troublealerts.Specialiconsaredisplayedto
visuallyshowthesystem’ scurrentcondition.
AC Power Icon
TheACpowericonindicatestheControlPanel’ sAC
linepowerstatus.Theicondisplaysawhiteplug
whentheACpowerispresent;theiconwilldisplay
withared“X”overthewhiteplugwhenACpower
isabsent.
Phone Line Failure Icon
IftheControlPaneldetectsthatthetelephoneline
isdisconnected,thephonelinefailureicon
appears.
Sounder Disabled Icon
Ifthesystem’ sinternalsounderhasbeenlowered
andexternalsounderhasbeendisabledbythe
installerfortesting,thesounderdisabledicon
appears.Italsoflashestoindicatesilentarming.
Backup Battery Status Icon
IftheControlPanel’ sbackupbatterytestslow,the
lowbackupbatteryiconappears.
Test Mode Icon
WhenthesystemisbeingtestedinWalkTest
Mode,thetestmodeiconwillbedisplayedonthe
statusbar.
Touch Screen Keypad Traffic Icon
WhentheControlPaneliscommunicatingtoa
touchscreenkeypadtheuparrowiconappears.
Whenatouchscreenkeypadcommunicatestothe
ControlPanelthedownarrowiconappears.
Cell Radio Icon
Ifthesystem’ soptionalcellradiomoduleis
installed,thecellradioiconappearswhilethe
ControlPanelisreceivingover‐the‐airfirmware
updates.
Interior Sensor Open Icon
Ifaninteriorsensorisopen(oramotiondetector
hasjustbeenactivated)thehouseiconappearson
thestatusbar.Asawarning,theiconflashesduring
arming.
