AMT/PTD/PBX/0058/4/6/EN Installation and Maintenance Manual - Aastra 5000
Page 126 01/2011 Description des sous-ensembles
The fuse holder is located between the "I/O" switch and the mains outlet.
The ADS 350XD is fitted with two 80 mm diameter fans located at the back of the power
supply module.
Connectors
The front panel of the power supply module has a mains socket.
Indicators
The ADS 350XD power supply modules have 6 indicators on the front panel, which give
the following information:
4.2.1.5 Hardware configuration
The mains voltage, 115 V or 230V (+/- 10%), is detected automatically, internally.
4.2.1.6 Installation and wiring
SYMBOL INDICATOR STATE EXPLANATION
On Line Power Present
On Battery connected
On Rectifier On
On Converter On
On Bell current generator On
On Fans present
TABLEAU 4.1 PRESENTATION OF ADS 350XD POWER SUPPLY
MODULE INDICATORS
48
