AMT/PTD/PBX/0058/4/6/EN Installation and Maintenance Manual - Aastra 5000
Page 358 01/2011 Installation and activation
Figure 6.2 CPU card fitted with two EIP cards
Installing a daughter card on a card requires the use of spacers. The EIP cards are
screwed onto the cards.
Combining 32-channel and 8-channel EIP cards
Both EIP cards must not have the same capacity on the same UCV card. For example, a
CPU card may be fitted on J13 with a 32-channel EIP card and on J14 with an 8-channel
EIP card.
On a DUPLEX system, this combination must be identical on the passive and active
cards.
