Installation and Maintenance Manual - Aastra 5000 AMT/PTD/PBX/0058/4/6/EN
Maintenance 01/2011 Page 403
7.2.7.4 Interchangeable fuses
Only power supply modules have interchangeable fuses.
TABLEAU 7.5 LIST OF INTERCHANGEABLE FUSES
7.2.7.5 lithium batteries of UCV cards
TABLEAU 7.6 LIST OF LITHIUM BATTERIES
7.2.7.6 Optional interchangeable batteries
TABLEAU 7.7 LIST OF OPTIONAL INTERCHANGEABLE BATTERIES
FUSE ITEM CODE AMPERAGE
ADS300XD power supply module fuses:
• mains protection (accessible on front panel)
• battery polarity inversion protection (F300 fuse
accessible on the power supply card)
PK925F
PK184M
3.15 A
6.3 A
• ADS300X power supply module fuses:
- mains protection (accessible on front panel)
- battery polarity inversion protection (F300 fuse
accessible on the power supply card)
PK925F
PK184M
3.15 A
6.3 A
• ADS150X power supply module mains protection fuses
(accessible on rear panel)
PK925D 2.5 A
INTERCHANGEABLE SUBASSEMBLY ITEM CODE
• Lithium batteries CR2032 type of UCV-L and UCV-S cards APK0008A
• Lithium batteries of UCV--D CR2450 type APK0012A
INTERCHANGEABLE SUBASSEMBLY ITEM CODE
• AXD and AXL cabinet battery (wall/rack) BHT7781A
• AXS, AXS12, AXS6 battery cabinet (wall/rack) BHR7061A
