AMT/PTD/PBX/0058/4/6/EN Installation and Maintenance Manual - Aastra 5000
Page 86 01/2011 Description et caractéristiques d’un PBX
• #8 to #13: indicates that the card can be equipped if no card in the short list is installed
in slot n in the main cabinet.
Exemple : If a PT2 + VOIP 16 card is installed in slot 1-00 (#8), a card from the short
list cannot be installed in slot 1-08, but a card from the full list can be
installed. If a PT2 + VOIP 16 card is installed in slot 1-00 (#9), a card from
the short list cannot be installed in slot 1-09, but a card from the full list can
be installed.
Exemple : If an LD4 or LD4N card is installed in slot 1-00 (#8), a card from the short list
cannot be installed in slot 1-08, but a card from the full list can be installed.
- Short list:
LA8, LN8, LM8, LH8, LI1, LR4, CP1, 8-channel PT2, MUM and 16-channel
PT2, LD4, LD4N for slots 00 to 05.
- Full list:
LA16X, LN16X, LA16X-8, LN16X-8, LH16X, LH16X-8, CS1, CA1, IPS, 32-
channel PT2, LT2, BTX. LD4X, 0-channel PT2 0.
3.5.1.2 A2XD and A3XD expansion cabinet
The slots in an expansion cabinet can only be fitted with certain equipment cards:
TABLEAU 3.6 POSSIBLE CONFIGURATIONS OF THE TWO EXPANSION
BACKPLANES OF AN AXD IPBX
CARDS A2XD and A3XD EXPANSION CABINET
CLX cards
LD4/LD4N/LD4X Not
LT2 Not
IPS Yes
PT2 8,16,32 channels Not
CS1 Not
CA1 Not
CP1 Not
MUM Not
Equipment cards
LA16X Yes
LA16X-8 Yes
LA8 Not
LN16X Yes
LN16X-8 Yes
LN8 Not
LM8 Not
LH8 Not
LH16X Yes
LH16X-8 Yes
LR4 Not
LI1 Not
BTX Yes
