Description et caractéristiques d’un PBX 01/2011 Page 73
3.2 Characteristics
3.2.1 Physical specifications
TABLE 3.1PHYSICAL CHARACTERISTICS OF AXD, AXL, AXS, AXS12, AND AXS6
PBXS
3.2.2 Electrical specifications
CHARACTERISTICS AXL cabinet AXS/AXS12/
AXS6 cabinet
MAIN
AXD
Height 310 mm
(7 U)
89 mm
(2 U)
450 mm (10 U)
Width 440 mm
(19")
440 mm (19") 440 mm (19")
Depth 316 mm 400 mm 316 mm
Max. weight 20 kg 7.5 kg 15 kg (simplex)
18 kg (duplex)
without
expansion
cards
and 28 kg in
total
ADS 350XD power supply module (AXD iPBX)
CHARACTERISTICS VALUES
Rated voltage 115 V or 230 V
Tolerances +/- 10%
Frequency 50 or 60 Hz
Power 350 W
Converter (48 V) +5 V / 15 A et -5 V / 0,5 A
+12 V / 0.5 A and -12 V / 0.65 A *
(* 0.25 A for cards and 0.40 A for fans)
-48 V / 2.9 A
ringer: 70 V / 0.2A
25-50 Hz (symmetrical current)
External battery (option) See Section 3.8.7.1
