Aastra AXD User Manual

AMT/PTD/PBX/0058/4/6/EN Installation and Maintenance Manual - Aastra 5000
Page 74 01/2011 Description et caractéristiques d’un PBX
ADS 300XD power supply module (AXD iPBX)
CHARACTERISTICS VALUES
Rated voltage 115 V or 230 V
Tolerances +/- 10%
Frequency 50 or 60 Hz
Power 300 W
Converter (48 V) +5 V / 15 A et -5 V / 0,5 A
+12 V / 0.5 A and -12 V / 0.65 A
(* 0,25 A for cards and 0,40 A for fans)
-48 V / 1.9 A
ringer: 70 V / 0.2A
25-50 Hz (symmetrical current)
External battery (option) See Section 3.8.7.1
ADS 350X power supply module (AXL iPBX)
CHARACTERISTICS VALUES
Rated voltage 115 V or 230 V
Tolerances +/- 10%
Frequency 50 or 60 Hz
Power 150 W
Converter (48 V)
+5 V / 15 A and -5 V / 0.5 A
+12 V / 0.15 A and -12 V / 0.65 A
-48 V / 2.9 A
ring 70 V / 0,2 A
25-50 Hz (symmetrical current)
External battery (option) See Section 3.8.7.1

Aastra AXD Specifications

General

Brand	Aastra
Model	AXD
Category	Server
Language	English
