AMT/PTD/PBX/0058/4/6/EN Installation and Maintenance Manual - Aastra 5000
Page 402 01/2011 Maintenance
* Card not provided
TABLEAU 7.3 LIST OF INTERCHANGEABLE AXL, AXS, AXS12 AND AXS6 IPBX
SUB-ASSEMBLIES (2/2)
7.2.7.3 Interchangeable AXD/AXL/AXS/AXS12/AXS6 iPBX cables
TABLEAU 7.4 LIST OF INTERCHANGEABLE AXD/AXL/AXS/AXS12/AXS6 IPBX
CABLES
INTERCHANGEABLE AXL, AXS, AXS12 and AXS6 iPBX
subassemblies
ITEM CODE
Equipment cards
• LA16X BHJ4431A
• LA16X-8 BHJ4431B
•LA8* HJ4714A
• LN16X BHJ4475A
• LN16X-8 BHJ4475B
•LN8* HJ4715A
•LM8 BHJ4726A
•LH8* HJ4716A
• LH16X BHJ4830A
• LH16X-8 BHJ4830B
• LR4D (with DTOC)
• LR4 (without DTOC)*
• FTXA (50 Hz charge detector)
• FTXC (12/16 KHz charge detector)
BHJ4717F
HJ4717A
HJ2817A
HJ2818A
• LI1 (+ cable) BHT7854A
•BTX BHJ4751A
INTERCHANGEABLE AXD/AXL/AXS/AXS12/AXS6 IPBX CABLE ITEM CODE
• RJ45-RJ45 cable (length 5 m)
for LA8, LN8, LM8, LA16 and LN16 cards
HG4765B
• RJ45-RJ45 cable (length 10 m)
for LA8, LN8, LM8, LA16 and LN16 cards
HG4765C
• Standard FTP cable (120 ohms, cat 5)
for LD4, LD4N, LD4X, LT2, PT2, and LR4 cards
HG4731
• AXS/AXS12/AXS6/AXD expansion cabinet cable BHT8212A
• AXL expansion cabinet cable BHG4784A
• Internal ribbon cable for AXS/AXS12/AXS6 expansion BHR0129A
• FULL NULL MODEM -PPP- UCV-PC CABLE BHG0024A
