Installation and Maintenance Manual - Aastra 5000 AMT/PTD/PBX/0058/4/6/EN
Installation and activation 01/2011 Page 337
6.2.6.3 Backup remote access to AMP in SSH mode
In case of AMP inaccessibility via the web browser, it is possible to connect securely to a
remote server integrated into Aastra X series systems (Linux Debien server) thanks to the
SSH protocol.
Note : An SSH client (Secure Shell) is used to connect securely to a remote server thanks to the
SSH protocol.
Using an appropriate communication software application (putty, for example) proceed as
follows:
• Run this application.
• Enter the IP address of the target Aastra X series system in the " Host Name" field.
• Enter the port number for this connection "2222" in the "Port" field.
• Click "Open".
A console screen is displayed.
• Enter the login " vt100 ".
• Enter the password " vt100 ".
Communication is set up.
On the following screen, select the access mode for the AMP user interface in VT100
