AMT/PTD/PBX/0058/4/6/EN Installation and Maintenance Manual - Aastra 5000
Page 50 01/2011 Description et caractéristiques d’un PBX
Figure 3.6 Overview of an A2XD cabinet in simplex configuration with secure power unit
RUCV-D card (A)
UCV-D card (A)
Expansion cards
Blanking plate
(empty slot)
Blanking plate
(empty slot)
Connection cable for AXD-A2XD (A)
Expansion cabinet
Main rack
Power supply module
Power supply module
Power supply module (power suppl
Power supply module
BTX card
(power supply module
(power supply modu
(power supply modul
