Aastra AXD

Installation and Maintenance Manual - Aastra 5000 AMT/PTD/PBX/0058/4/6/EN
Description et caractéristiques d’un PBX 01/2011 Page 71
Figure 3.19 Overview of an AXS6 cabinet
UCV-Scard
Fresh air inlet
Power supply
Hot air outlet
Expansion card
EXT1-S6 card
