Installation and Maintenance Manual - Aastra 5000 AMT/PTD/PBX/0058/4/6/EN
Description des sous-ensembles 01/2011 Page 281
TABLEAU 4.77 DESCRIPTION OF LH16X CARD CONNECTORS
Indicators
This card has no signalling indicator.
4.14.11.4 Hardware configuration
This card has no configuration microswitch.
4.14.11.5 Installation and wiring
The LH16X card can be hot-plugged in an AXD, AXL, AXS or AXS12 iPBX in normal
operation.
The LH16X card has the same installation and wiring details as those of the LA16X card
(see Section4.14.1.5).
The minimum diameter of the cables has to be 26AWG (0.4mm).
NAME FUNCTION/CHARACTERISTIC CONTACTS
J1 96-pin connector:
backplane connection
A0 to A15 RJ45 connectors: each socket
provides one connection to an
analogue hotel/motel set
•Pin 4:
analogue set (i)+
•Pin 5:
analogue set (i)-
• Pins 1, 2, 3, 6, 7, and 8:
NC
