Installation and Maintenance Manual - Aastra 5000 AMT/PTD/PBX/0058/4/6/EN
Description des sous-ensembles 01/2011 Page 283
TABLEAU 4.78 DESCRIPTION OF LH16X-8 CARD CONNECTORS
Indicators
This card has no signalling indicator.
4.14.12.4Hardware configuration
This card has no configuration microswitch.
4.14.12.5Installation and wiring
The LH16X-8 card can be hot-plugged in an AXD, AXL, AXS or AXS12 iPBX in normal
operation.
The LH16X-8 card has the same installation and wiring details as those of the LA16X card
(see Section4.14.1.5).
The minimum diameter of the cables has to be 26AWG (0.4mm).
NAME FUNCTION/CHARACTERISTIC CONTACTS
J1 96-pin connector:
backplane connection
A0 to A7 RJ45 connectors: each socket
provides one connection to an
analogue hotel/motel set
•Pin 4:
analogue set (i)+
•Pin 5:
analogue set (i)-
• Pins 1, 2, 3, 6, 7, and 8:
NC
81
