Figure 3.5 Overview of an AXD cabinet in simplex configuration with secure power unit
Power supply module (p
Power supply module (pow
IUCV-D card
UCV-D card (A)
Expansion cards
Blanking plate
(empty slot)
Blanking plate
(empty slot)
BTX card
