Page #144 background image
AMT/PTD/PBX/0058/4/6/EN Installation and Maintenance Manual - Aastra 5000
Page 144 01/2011 Description des sous-ensembles
USB (A)
(1)
USB connector in HOST mode • Pin 1: PWR0
• Pin 2: DNEG0
• Pin 3: DPOS0
•Pin 4: GND
USB (A)
(1)
USB connector in HOST mode • Pin 1: PWR1
• Pin 2: DNEG1
• Pin 3: DPOS1
•Pin 4: GND
ETH1
(1)
RJ45 connector • Pin 1: RXP
• Pin 2: RXM
•Pin 3: TXP
•Pin 4: TLBR
•Pin 5: TLBR
•Pin 6: TXM
• Pin 7: RLBR
• Pin 8: RLBR
ETH2
(1)
RJ45 connector:Connection used for the access
Administration in the case of configuration of
separation of the networks Administration and
Telephony.
(refer to Manual AMT/PTD/PBX/0101).
• Pin 1: RXP
• Pin 2: RXM
•Pin 3: TXP
•Pin 4: TLBR
•Pin 5: TLBR
•Pin 6: TXM
• Pin 7: RLBR
• Pin 8: RLBR
NAME FUNCTIONS/CHARACTERISTICS CONTACTS
(1) Connector front view.
TABLEAU 4.5 DESCRIPTION OF UCV-D CARD CONNECTORS
