AMT/PTD/PBX/0058/4/6/EN Installation and Maintenance Manual - Aastra 5000
Page 162 01/2011 Description des sous-ensembles
• Simplex configuration: connecting UCV-D (B) / RUCV-D (B) (see Figure 4.17 )
- Install the yellow clamps at each end of the AXD-A2XD connection cable.
- Install the blue clamps at each end of the AXD-A3XD connection cable.
Figure 4.17 C
ONNECTING TWO EXPANSION CABINETS (SIMPLEX CONFIGURATION, UCT-D(B)-
RUCT-D(B))
To Next Page
