AMT/PTD/PBX/0058/4/6/EN Installation and Maintenance Manual - Aastra 5000
Page 300 01/2011 Description des sous-ensembles
Indicators
*LD1 located on the card circuit (and not on front panel)
TABLEAU 4.88 PRESENTATION OF THE BTX CARD INDICATORS
Jumpers
TABLEAU 4.89 PRESENTATION OF THE BTX CARD JUMPERS
NAME STATE EXPLANATION
LD1 On steady (green)
On green/red alternating
Green flashing
Red flashing
Normal buffer operation
iPBX data received on the serial ticket port
Pre-alarm: 80 % total memory used
Alarm: 95 % total memory used
NAME FUNCTION
J2 • Set INT side: indicates buffer power supplied by the iPBX
• Set EXT side: indicates buffer power supplied by connector J8 (external
supply)
J3
• If set, indicates memory power supplied by the buffer battery
