Installation and Maintenance Manual - Aastra 5000 AMT/PTD/PBX/0058/4/6/EN
Maintenance 01/2011 Page 429
• Check the configuration of
the card.
• For a card with micro-switches, check that these latter are
configured as they were on the old card, unless the configuration
has been changed (in which case, see Section 4.3).
• As the card may have daughter cards, check that it is fitted in the
same way as the previous one, unless its configuration has been
modified due to a change in its capacity (in which case, see
Section 4.3 and/or the product “Data sheet”).
• Insert the new card into its
slot.
• Slide the card along the card guides until it clicks into place.
• Lock the card in place using the 1/4 turn locks (see Figure 4.1 ).
Nota : The UCV-D card can be hot-plugged in an
operational AXD iPBX.
• Activate the passive UCV-
D card from the
AMP.
See Section 1.3 Document [1].
Nota : This new card is now the passive card and must
be activated so that the system can take it into
account, and to fully synchronise as soon as
possible the active card and the new passive card
(software, data, announcements, IVR, etc.). This
passive card will only become active during the
next switchover.
• Perform a software check.
• Check the software release of the card on the
AMP (see
document [1]).
• Contact your distributor if the details do not coincide.
• Check the UCV-D card
indicators.
Refer to Section 4, Description des sous-ensemblesError! No
bookmark name given.
• Back up the customer
configuration.
.
Table 14:
OPERATION DETAILS OF THE OPERATION / COMMENTS
